The DOF Reality PRO 4 Professional Helicopter Motion Simulator Platform is a commercial-grade rotary-wing simulation system engineered for advanced helicopter training, enthusiast simulation rooms, and professional motion-based flight environments. Featuring Pitch, Roll, Yaw/Directional Rotation, and Heave movement, the PRO 4 delivers highly immersive helicopter motion feedback designed to reproduce realistic low-altitude flight behavior and vertical aircraft dynamics.
Unlike seat-only systems, the PRO 4 moves the complete cockpit assembly—including the seat, cyclic, collective, pedals, throttle controls, and mounted displays—allowing pilots to experience synchronized helicopter movement through physical body positioning and motion-based directional feedback.
4-Axis Rotary-Wing Motion Simulation
- Pitch & Roll Movement: Simulates forward flight transitions, banking corrections, hover adjustments, and lateral helicopter movement.
- Yaw / Directional Rotation: Reproduces tail rotor directional changes, heading corrections, rotational input, and coordinated maneuvering.
- Integrated Heave Motion: Adds vertical aircraft feedback for lift changes, sink rate, turbulence, hover oscillation, touchdown impact, and ground effect simulation.
- Unified Cockpit Motion: The full control environment moves together as a synchronized platform for more realistic spatial orientation and motion immersion.
Professional Simulator Construction
- Commercial-Grade Metal Structure: Reinforced metal profiles engineered for continuous operation and demanding simulation environments.
- High-Speed Motion Response: Designed for responsive telemetry-driven movement and precise low-speed helicopter maneuver simulation.
- Extended Session Capability: Suitable for aviation training environments, commercial simulator installations, and enthusiast helicopter simulation rooms.
- Helicopter Flight Control Compatibility: Supports cyclics, collectives, rudder pedals, throttles, HOTAS systems, and multiple rotary-wing control layouts.
Telemetry Software & Motion Integration
- Sim Racing Studio License Included: Converts real-time helicopter telemetry into synchronized physical platform movement.
- Detailed Rotary-Wing Feedback: Reproduces turbulence, vibration, lift transitions, hover corrections, touchdown forces, sink rate, and dynamic aircraft loading.
- Adjustable Motion Profiles: Fine-tune movement intensity, responsiveness, and smoothing based on aircraft type or pilot preference.
- Broad Flight Simulator Compatibility: Supports many popular PC-based helicopter and aviation simulation platforms.
Technical Specifications
| Degrees of Freedom | 4DOF (Pitch + Roll + Yaw + Heave) |
| Motion Type | Full Platform Motion |
| Range of Motion | 20° |
| Speed | 75 cm/s (105°/s) |
| Torque | 28 Nm |
| Acceleration | 0.75G T / 0.5G L |
| Power Consumption | 750W Peak |
| Supported Pilot Weight | 440 lbs / 200 kg |
| Platform Footprint | 3×5 ft | 2 ft Height |
| Shipping Weight | Approx. 175 lbs Combined |
| Construction Material | Commercial Grade Metal Profiles |
| Warranty | 1-Year Manufacturer Warranty |
What’s Included & Important Information
Included with Platform:
- DOF Reality PRO 4 Helicopter Motion Simulator Platform
- Integrated Motion Drive System
- USB Motion Control Unit (100–240V)
- Sim Racing Studio Software License
- Assembly Hardware & Tools
- Required Cables & Power Components
Important: This listing includes the motion platform only. Helicopter controls, cyclics, collectives, rudder pedals, VR headsets, monitors, and simulation software are sold separately unless otherwise specified.
| Specification name | Specification Value |
|---|---|
| Color pattern | Black |
| Connectivity technology | USB |
| Material | Metal |
