The Thrustmaster HOTAS Warthog Dual Throttles is a 1:1 scale replica of the U.S. Air Force A-10C throttle system, engineered for high-fidelity combat and engine management on Windows PC.
Built with a 100% metal base and metal throttle handles, this unit utilizes H.E.A.R.T (HallEffect AccuRate Technology) with 3D magnetic sensors providing 14-bit resolution (16,384 values) per throttle. The system features independent dual-engine control with a locking mechanism and a control panel equipped with industrial-grade switches and a dedicated 2-axis "mouse" mini-stick.
Dual Throttle & Pull-and-Push Detents
- Independent Dual Throttles: Features two independent levers with a mechanical interlock to allow either simultaneous or independent engine management.
- Afterburner & Idle Detents: Utilizes a "Pull-and-Push" mechanical system for realistic engagement of the Idle and Afterburner gates.
- Metal Build: Both the throttle handles and the base plate are constructed from die-cast and brushed metal, totaling over 9 lbs (4 kg) for maximum desk stability.
- Adjustable Tension: A physical dial on the base allows users to increase or decrease the travel resistance of the throttle levers.
Control Panel & Sensor Precision
- H.E.A.R.T Technology: Frictionless magnetic sensors eliminate mechanical potentiometers, ensuring precision that does not degrade over time.
- Backlit Control Panel: Features a dedicated control surface with 5 programmable LEDs and 15 action buttons, including industrial-spec toggles.
- Slew Control: Integrated 2-axis mini-stick (mouse) with a push button, calibrated for precise target slewing or radar cursor management.
- TRIM Wheel: High-precision rotary wheel for manual axis trimming during flight.
Comprehensive Input Layout
-
Throttle Inputs: 17 action buttons in total across the handles, including:
- 1 x 8-way "Point of View" hat switch.
- 1 x 4-way hat switch with push button.
- 1 x 3-position switch (2 permanent + 1 momentary).
- 2 x 3-position switches (3 permanent).
- Base Inputs: 15 action buttons + 1 TRIM wheel, utilizing realistic pressure switches for tactile feedback.
Compatibility & PC Software
- Platform: Native plug-and-play support for Windows 10 and 11 via USB.
- T.A.R.G.E.T Suite: Fully compatible with the Thrustmaster Advanced pRogramming Graphical EdiTor for creating advanced macro sequences and custom axis curves.
- Simulator Support: Pre-calibrated for DCS World, IL-2 Sturmovik, Star Citizen, and Microsoft Flight Simulator.
What’s in the Box
- 1 x Thrustmaster HOTAS Warthog Dual Throttles.
- 1 x Integrated Control Panel Base.
- Quick Start Guide and Technical Warranty Documentation.
Technical Specifications Summary
| Sensor Type | 14-bit Magnetic (H.E.A.R.T) |
| Levers | Independent Dual Throttles |
| Action Buttons | 32 Total (Handles + Base) |
| Detents | Idle and Afterburner (Mechanical) |
| MPN | TM-WARTHOG-THROTTLE |
| Specification name | Specification Value |
|---|---|
| Color pattern | Black |
| Connection type | Wired |
| Connectivity technology | USB |
| Power source | USB |
