The Next Level Racing® Round Tube Freestanding Triple Monitor Stand is a structural display solution designed to support multi-monitor configurations for racing and flight simulation.
Constructed from 50mm carbon steel round tubing, this freestanding frame supports up to three 43-inch monitors. The independent design allows for custom positioning relative to the cockpit, providing structural isolation from simulator vibrations.
Technical Features
- Multi-Screen Support: Accommodates 3 x monitors from 21” to 43”.
- Alignment Accuracy: Laser-etched markings on the tubing for symmetrical arm placement.
- Anti-Sag Adjustment: Screw-thread VESA adjusters for fine-tuning individual screen height and angle.
- Structural Foundation: 50mm carbon steel tubing with dual crossbars for load management.
- Mobility: Includes both height-adjustable feet and lockable castor wheels.
Structural Specifications
Fabricated from heavy-gauge 50mm carbon steel, this stand is engineered to maintain alignment for triple-screen arrays. The telescopic design allows for height and angle calibration to suit various seating positions.
- Independent Foundation: Freestanding design facilitates easier cockpit upgrades and maintenance.
- Load Management: Dual crossbar reinforcement reduces mechanical flex under the weight of large displays.
- Base Clearance: 84cm (33") internal width to straddle various simulator chassis.
VESA Adjustment & Calibration
Accurate bezel alignment is achieved through precision screw-thread adjusters located on each VESA mounting point. This hardware allows for per-screen tuning of height, tilt, and lateral angle.
- Per-Screen Calibration: Fine-tune horizontal alignment across all three displays.
- Reinforced Side Arms: Increases structural integrity at the outer pivot points.
- VESA Range: Compatible with patterns from 75x75mm up to 800x400mm.
Compatibility
- Next Level Racing® Racing and Flight Cockpits.
- Compatible with third-party cockpits with an external width of less than 84cm.
- Supports standard flat and curved monitors within weight and size limits.
Package Contents
- Next Level Racing® Round Tube Freestanding Triple Monitor Stand
- 4 x Lockable castor wheels and 4 x Height-adjustable feet
- VESA mounting hardware and tool kit
- Assembly instructions
Specifications
- Supported Screens: 3 × 21”–43”
- Weight Capacity: Center: 50 kg (110 lbs); Outer: 30 kg (66 lbs) each.
- VESA Range: 75x75mm up to 800x400mm
- Inner Clearance: 84 cm / 33 inches
- Max Assembled Dimensions: 204 x 95.6 x 141 cm
- Product Weight: 20.8 kg / 45.9 lbs
- MPN: NLR-A011
| Specification name | Specification Value |
|---|---|
| Color pattern | Black |
| Mount/Stand features | Adjustable angle, Adjustable dimensions, Telescopic, Portable, Easy to install, Swivel |
