• Resolution: 3,552 × 3,840 pixels per eye (Micro-OLED architecture).
• Color Accuracy: 95% DCI-P3 color gamut coverage for professional-tier color reproduction.
• Refresh Rates: Variable support for 60Hz, 72Hz, and 90Hz.
• Field of View: 109° horizontal and 100° vertical immersion.
• Pixel Pitch: 6.3-micron pitch designed to minimize the "screen-door effect" and improve text legibility.

• Processor: Snapdragon® XR2+ Gen 2 chipset optimized for concurrent sensor processing and XR rendering.
• Memory: 16 GB high-speed RAM for intensive multitasking and high-asset environments.
• Onboard Storage: 256 GB flash storage.
• Security: Integrated iris recognition for biometric authentication and secure application access.

The Galaxy XR features a multi-modal sensor suite for spatial awareness and user interaction:

• Pass-Through: Two high-resolution cameras for color-accurate mixed reality visualization.
• Environmental Tracking: Six world-facing cameras and five Inertial Measurement Units (IMUs).
• User Interaction: Four eye-tracking cameras for foveated rendering and eye-controlled navigation.
• Depth Sensing: Dedicated depth sensor and flicker sensor for precise object occlusion and light matching.
• Spatial Capture: Supports 3D photo and video acquisition (18mm, F2.0 optics).

• Speaker Logic: Dual 2-way integrated speakers (dedicated woofer and tweeter) with Dolby Atmos support.
• Microphone Array: Six-microphone system with beamforming technology for voice clarity.
• Video Engine: Supports UHD 8K playback at 60fps with HDR10 and HLG compatibility.
• Wireless Standards: Wi-Fi 7 (802.11be) and Bluetooth 5.4 for low-latency data and peripheral syncing.

• Weight: 1.20 lb headset (with forehead cushion); 0.67 lb external battery pack.
• Battery Life: Up to 2 hours of general computing; 2.5 hours of dedicated video playback.
• Charging: Supports continuous use while connected to a power source.
• Optics Fit: Adjustable Interpupillary Distance (IPD) from 54–70 mm.
• Vision Correction: Compatible with optional magnetic optical inserts (sold separately).
